Nomex® Honeycomb
Lightest Possible Construction

Parts which require minimum weight often employ Nomex® Honeycomb sandwich cores. Our #1562 and #2562 are .210" cut thickness with 3/16" over expanded cells. #1562 is 1.8 lb/cu ft. density and #2562 is 3.0 lb/cu ft. Over expanded cell structures allow both to be quite flexible, making them perfect for use in tight radius curves. All of our resins will bond well to the phenolic coated honeycomb, reducing peel. Nomex® is a registered trademark of E.I. DuPont De Nemours & Co.
Vinyl Foam: Divinycell 5 lb. Density
Highest Strength Foam

Looking to make a strong composite part? DIAB® closed cell vinyl foam is an excellent choice. 5lb vinyl foams add significant strength to a laminate when used as a sandwich core. With compressive strengths over 200psi, these foams offer more strength to a laminate than light weight honeycombs with only a minor weight penalty. This allows them to be used extensively in applications where ultimate laminate strength is of the utmost importance. Still significantly lighter weight than a traditional composite lamination, 5lb foams are used extensively in high strength structural building, aerospace, and design applications.

Offering significant strength and impact resistance to a laminate, 3/8" thick foam is commonly used for exterior vehicle structures, boat hulls, and bulkheads. 1/2" thick foam offers the highest strength to a composite part possible. Applications for 1/2" vinyl foam include load bearing structural supports, structural walls, unsupported flooring, and other high strength parts.

Vinyl Foams are compatible with all of our resins and can be easily thermoformed with a heat gun or oven. DIAB® Divinycell H80 5 Lb. Density.

1495 & 1496 are 32" X 48" Sheets.
End Grain Balsa
Most Popular Core Material

End Grain Balsa is the most widely used core material. We offer three grades of marine grade balsa, all available in 2' x 4' sheets of individual small blocks of end grain balsa bonded to a light scrim fabric that holds the blocks together during lamination. Sheets of this core will conform to practically any simple curve and most gradual compound curves. 9.5# density.

Guidelines for Sandwich Core Materials

The rising demand for new materials with higher strength to weight ratios has created a dramatic growth in sandwich composite technology. Sandwich construction employs a lightweight core that has a flexural strength and flexural modulus far exceeding that of the skin laminates alone.

The normal method of building a composite sandwich is to laminate the outer skin by conventional means in a mold then lay the core material into the wet laminate. The inner skin is laminated onto the top of the core material effectively sealing it. Sandwich core laminates of this type are used to stiffen various composite applications such as boat hulls, automobile hoods, molds, and aircraft panels. By increasing the core thickness, you can increase the stiffness of the sandwich without substantially increasing weight and cost.

The most common types of core materials are:

  1. Nomex® Honeycomb
  2. Vinyl Sheet Foam
  3. End Grain Balsa
  4. Polyurethane Foam
  5. Mix and Pour Polyurethane Foam



Honeycomb is a series of cells, nested together to form panels similar in appearance to the cross-sectional slice of a beehive. In its expanded form, honeycomb is 90-99 percent open space. Nomex honeycomb is fire retardant, flexible, lightweight, and has good impact resistance. It offers the best strength to weight ratio of the core materials. Nomex honeycomb is used primarily for structural applications in the aerospace industry.

Vinyl sheet foam is one of the most versatile core materials on the market. It is a rigid, closed cell material that resists hydrocarbons, alkalis, dilute acids, methyl alcohol, sea water, gasoline, diesel oil, and it is self extinguishing. It has been used extensively in aircraft and performance automotive structures, but it can be applied anywhere that high properties and easy handling are needed. Vinyl foam can be thermoformed in an oven or with a heat gun while applying gentle pressure. For ultimate peel strength, use a perforation roller to increase the surface area of the foam. The peel strength will increase an additional 15-20% after perforation.

End-grain balsa is the most widely used core material. It is both a relatively high strength core and less expensive than vinyl or honeycomb. It achieves its high compression strength because on a microscopic level it has a honeycomb type of structure yet is quite dense. It is easy to cut and bevel and is available in 29x49 inch sheets. The individual small blocks of end grain balsa are bonded to a light scrim fabric which makes the sheet quite flexible.

This sheet foam is a rigid, closed cell material with excellent thermal insulation and flotation properties. This core has been at the heart of the marine industry for decades and is fairly inexpensive when a lower property cored laminate is needed. It is compatible with both polyester and epoxy resin systems.

This foam is a rigid, closed cell material with excellent thermal and floatation properties. While it is not generally suited to the classic sandwich core laminate described in this brochure, it can be poured into any closed cavity to stiffen the structure. The free rise density is 2 lbs. per cubic foot, but closed mold techniques can increase the density when required. Small amounts of this foam may be added to the Nomex honeycomb to fill the cells. The filled honeycomb is then much easier to bevel and shape.

Practical Guide to Handling the Core Materials

To maintain the effectiveness of the sandwich structure three conditions must be met. First, the core must be strong enough to withstand the compressive or crushing load placed on the panel. If the core collapses, the mechanical stiffness advantage is lost. Second, the load bearing skins must form a rigid bond to the core surfaces so the skins don't creep or peel during use. This interface is called the BOND LINE. Finally the core must resist the shear forces involved. If the core shears, the skins shift and the mechanical advantage is again lost.

Once the proper core material has been selected based upon compressive and shear strengths, the skills of the fabricator become critical in determining the quality of the bond line. Here are some helpful hints for maximizing the strength of the bond line.

  1. Increase the Surface Area
  2. Increase the Pressure



To guide the fabricator through real world production obstacles care should be taken to:

  1. Carefully bevel the edge of the core
  2. Reinforce all holes cut or drilled through the core
